Intel’s Diamond Rapids Xeon 7 CPUs: A Deep Dive into the Next-Gen Architecture

Intel's upcoming Xeon 7 platform, codenamed Diamond Rapids, promises significant advancements in core count and architecture, although its launch has been delayed until 2027.

Intel’s Xeon 7 platform, known as Diamond Rapids, is set to redefine high-performance computing with its ambitious architecture. Originally slated for release in 2026, the launch has been postponed to 2027, allowing Intel’s engineering team to refine the technology further.

At the recent Hot Chips conference, Intel disclosed that the flagship SKU of Diamond Rapids will feature an impressive 256 performance cores per socket, surpassing earlier expectations of 192 cores. This positions the platform to compete directly with AMD’s sixth-generation Venice Epycs, which also max out at 256 cores.

Targeted Applications

Diamond Rapids is not intended for mainstream use; it is designed specifically for high-core-count applications in high-performance computing (HPC). Notably, the platform will not support hyperthreading, which Intel refers to as simultaneous multithreading, limiting its appeal in certain enterprise scenarios. The focus will be on high-end application processors (AP) rather than standard server processors (SP).

Architectural Innovations

The architecture of Diamond Rapids reflects a significant evolution in Intel’s design philosophy. The chip will utilize a modular approach with up to 22 chiplets, allowing for flexible configurations based on compute, cache, and memory requirements. This modularity is reminiscent of AMD’s chiplet architecture but employs different manufacturing techniques.

Diamond Rapids will incorporate up to 16 core compute dies built on Intel’s advanced 18A-P process technology, alongside Compute Building Block (CBB) base dies and fabric hub dies. Each core chiplet will house up to 16 cores, with the CBB die containing a substantial 1.28 GB of L3 cache for the highest-end configurations.

Memory and I/O Capabilities

Intel’s design for Diamond Rapids includes two scalable fabric hub (SFH) dies, which integrate memory controllers and I/O interfaces. This configuration supports up to 16 channels of DDR5 memory, operating at speeds of 8,000 MT/s, and an extensive 128 lanes of PCIe 6.0 connectivity. This design aims to provide uniform memory access (UMA), a shift from the non-uniform memory access (NUMA) architecture seen in previous generations.

Despite the advancements, several details about Diamond Rapids remain unclear, including core clock speeds and IPC gains compared to previous models. The introduction of updated AMX instructions and full support for AVX 10.2 indicates a focus on enhancing performance for machine learning workloads.

As the launch approaches, Intel’s ability to deliver competitive pricing and performance will be crucial in determining the success of Diamond Rapids in the HPC market.
